Generator : Ring safe
Kind of M/C | GENERATOR ( 100 KVA. ) |
Inventory No. | 100-28 |
Serial No. | 3897359 |
Dimention (W x L x H) | 145 x 330 x 230 cm. |
Purchase Date | 16/10/2015 |
Engine No. | 6BG1-354945 |
Trade Name | DENYO DCA 100 ESI |
Weight (2 Jan 14Kg.) | 3,000 Kg. |
Purchase Date | : | 16 Oct 15 | |||||||
Engine No. | : | ISUZU 6BG1-354945 | |||||||
Trade Name | : | DENYO DCA 100 ESI | |||||||
Weight ( Kg. ) | : | 3,000 Kg. | |||||||
ALTERNATOR | DCA-100ES | ||||||||
Frequency Hz | 50 | 60 | |||||||
Output Rating (kVA) | Continuous | 80 | 100 | ||||||
Standby | 88 | 110 | |||||||
No.of Phases | 3-Phase,4-Wire | ||||||||
Rated Voltage V | 2 Dual Voltage | ||||||||
Power Factor | 0.8 (Lagging) | ||||||||
Voltage Regulation % | Within ± 0.5 | ||||||||
Excitation | Brushless,Rotating Exciter (With A.V.R.) | ||||||||
Insulation | Class F | ||||||||
ENGINE | ISUZU | ||||||||
MaKe&Model | DD-6BG1T | ||||||||
Type | Inlined,Direct Injected,Turbocharged | ||||||||
Output Rating | PS/rpm | 100/1500 | 124/1800 | ||||||
Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap Bitmap
|
73.6/1500 | 91.3/1800 | |||||||
No.of Cylinders-Bore X Stroke mm | 6-105 X 125 | ||||||||
Piston Displacement L | 6.494 | ||||||||
Fuel | ASTM No.2 Diesel Fuel or Equivalent | ||||||||
Fuel Consumption L/h | 13.5 | 17.4 | |||||||
Lube Oil Sump Capacity L | 22.4 | ||||||||
Coolant Capacity L | 22 | ||||||||
Battery X Quantity | 95D31R X 2 | ||||||||
Fuel Tank Capacity L | 225 |
